MAHLE X20 BASIC Service Kit: PF46-24

The MAHLE X20 Basic Kit is designed for dealers servicing X20-equipped eBikes, bringing together the key sensors, tools, connectors and charging components required for diagnosis and workshop support. It includes torque and cadence sensor options for multiple bottom bracket standards, plus the service tools needed to work safely with MAHLE X20 systems.

Features
• Designed for X20 system service and diagnostics
• Includes TCS Torque and Cadence Sensor for Bottom Bracket
• TCS options available for BB86, PF46-30, BB92 and PF46-24
• Includes PAS Sensor for X Series
• Includes iWoc ONE Head Unit – STD
• Includes Unit Torque Sensor Removal Toolset
• Includes TCS bearing extractor toolset
• Includes Magnet Locknut 11 Speeds
• Includes X20 Dropout Connector 550mm
• Includes Active Charging Point
• Includes Active Charger + GCU

Specifications
Brand: MAHLE
Product Type: X20 Basic Service Kit
System Compatibility: X20 System
TCS BB86 Part Code: 41010400002000
TCS PF46-30 Part Code: 41010400011000
TCS BB92 Part Code: 41010400022000
TCS PF46-24 Part Code: 41010400005000
PAS Sensor Part Code: 40010400000100
iWoc ONE Head Unit – STD Part Code: 34010400000100
Unit Torque Sensor Removal Toolset Part Code: 41010471000000
TCS Bearing Extractor Toolset Part Code: 41010470001000
Magnet Locknut 11 Speeds Part Code: X3540100001000
X20 Dropout Connector 550mm Part Code: 60010410000000
Active Charging Point Part Code: 28010400000000
Active Charger + GCU Part Code: 2501050003000
PAS Sensor Pin Length: 5mm
Head Unit Connectivity: BLE, ANT+, LEV and CAN
Dropout Connector Length: 550mm
Charger: Active Charger, up to 4A
Firmware Support: GCU required for SmartBike firmware updates
